| Key Feature |
|
DF-100 |
|
| Product Size |
|
100(W) * 97(H) * 22(D) mm |
|
| CPU |
|
TIOMAP 1621 |
|
| OS |
|
Windows CE.Net 4.2 |
|
| Memory |
|
128MByte NAND Flash |
|
|
64Mbyte SDRAM |
|
|
Expansion |
|
SD Card(slot) |
|
| Display |
|
Size |
|
3.5″ LTPS 256K Color LCD, Resolution 320*240 |
|
|
Type |
|
Transflective with LED Backlight Swivel type |
|
| Codec |
|
Video |
|
MPEG-4, H.264, WMV |
|
|
Audio |
|
AAC, MPEG-4 HE AAC ( = AAC+or AAC+SBR)MP3,
OGG, WMA |
|
| Picture View |
|
JPEG Viewer |
|
| Audio-In/Out |
|
Speaker out |
|
0.6W * 2channel * 2EA |
|
|
Earphone out |
|
7mW * 2channel. ø2.5mm |
|
| TV-Out |
|
VGA (Resolution 640*480) |
|
| PC Interface |
|
USB |
|
2.0 high speed |
|
|
Service Port |
|
Serial 2 channel |
|
|
DC in port |
|
Standard 24pin I/O |
|
| Battery |
|
Rechargeable and Removable 2100mA Li-polymer Battery |
|
|
|
|
|
|
|
